ColaBox L2 Plus Complete User Manual & Setup Guide

What's in the Box

Your ColaBox L2 Plus package includes everything needed for immediate setup:

ColaBox L2 Plus streaming device (×1)
Bluetooth Voice Remote + 2× AAA Batteries (×1)
HDMI 2.0 Cable (×1)
Power Adapter (×1)
USB-C Power Cable (×1)
Free Mini Wireless Keyboard (×1) — $35 value
Quick Start Guide (×1)
365-Day Warranty Card (×1)

💡 Tip: Keep the original packaging for warranty claims and safe transport.

Device Overview & Ports

Front Panel

LED status indicator
IR receiver window

Rear Panel

HDMI — 4K HDR output to TV
2× USB Type-C — Power & data
Ethernet (RJ45) — Wired network

Technical Specifications

Specification	Details
Processor	GK63 Quad-Core 64-bit ARM Cortex A55
RAM	4 GB
Storage	64 GB
Operating System	Android 14
Video Output	4K HDR
Wi-Fi	Dual Band 2.4GHz + 5GHz (802.11 a/b/g/n/ac)
Bluetooth	Bluetooth 5.0
Ports	2× USB Type-C + 1× HDMI
Power	DC 5V / 2A (Power Adapter included)

Initial Setup & First Boot

Connect to TV

Plug the included HDMI cable into the HDMI port on the ColaBox L2 Plus and into an available HDMI port on your TV.

Power On

Connect the USB-C power cable to the device and plug the adapter into a wall outlet. The LED indicator will turn on.

Select TV Input

Switch your TV to the correct HDMI input (e.g., HDMI 1, HDMI 2). The ColaBox boot screen will appear within 30 seconds.

Pair the Remote

Hold the Home and Back buttons simultaneously for 3 seconds to enter Bluetooth pairing mode. Follow the on-screen prompt.

Select Language & Region

Choose your preferred language and region. This affects system UI, time zone, and content recommendations.

Connect to Wi-Fi or Ethernet

Select your network and enter the password. For the most stable 4K streaming experience, use a wired Ethernet connection.

Sign In to Google Account

✅ Ready! You're ready to watch. All channels and apps are pre-installed — no additional setup needed.

Remote Control Guide

Button	Function
Power	Turn device on / standby
Home	Return to Android TV home screen
Back	Go to previous screen
D-Pad (↑↓←→)	Navigate menus
OK / Select	Confirm selection
Microphone 🎤	Voice search
Volume +/−	Adjust TV volume (via HDMI-CEC)
Mute	Mute / unmute audio
Settings ⚙️	Open quick settings panel

💡 Tip: The remote supports HDMI-CEC. Enable CEC on your TV to control TV power and volume with the ColaBox remote — no need to juggle two remotes.

Network & Wi-Fi Connection

📶 Wi-Fi Setup

Go to Settings → Network & Internet → Wi-Fi. Select your network, enter the password, and connect. Use the 5GHz band for faster, more stable streaming.

🔌 Wired Ethernet Recommended

Plug an Ethernet cable into the RJ45 port on the device. It connects automatically — no additional setup required.

⚠️ Note: For 4K HDR streaming, a minimum of 25 Mbps download speed is recommended. Switching from Wi-Fi to Ethernet typically resolves buffering.

Installing & Managing Apps

The ColaBox L2 Plus runs Android 14 with full access to the Google Play Store. All major streaming apps come pre-installed out of the box.

📦 Google Play Store

Open the Google Play Store from the home screen.
Search for the app (e.g., Netflix, Disney+, Plex).
Select Install and wait for download to complete.

🔧 Sideload APKs (Advanced)

Enable Unknown Sources in Settings → Security.
Transfer the APK via USB drive or download via browser.
Use a file manager to locate and install the APK.

Display & Picture Settings

Navigate to Settings → Display & Sound → Picture to configure:

ResolutionAuto / 4K (3840×2160) / 1080p / 720p
Refresh RateAuto / 60Hz
HDR ModeAuto-detect
Color SpaceAuto

💡 Tip: Set Resolution and Refresh Rate to Auto for best compatibility with your TV.

Audio Settings

Navigate to Settings → Display & Sound → Audio:

Bluetooth AudioConnect headphones for private viewing
Audio PassthroughSet to Auto for AV receivers
Volume ControlUse remote or HDMI-CEC

💡 Tip: ColaBox L2 Plus supports Bluetooth 5.0 — pair wireless headphones for late-night watching without disturbing anyone.

Storage & Memory Management

💾 Internal Storage

The device has 64GB internal storage — one of the largest in its class. View usage at Settings → Device Preferences → Storage.

🔌 Expand via USB

Connect a USB drive via the USB Type-C port for additional media storage.

⚠️ Warning: If formatting a USB drive as internal storage, all data on that drive will be erased. Back up files first.

FAQ & Troubleshooting

FAQNo signal on TV

Make sure your TV is set to the correct HDMI input. Try a different HDMI cable or port. Confirm the LED on the device is lit.

FAQRemote not responding

Re-pair the remote: hold Home + Back for 3 seconds. Replace batteries if the remote LED does not flash when pressing buttons.

FAQWi-Fi keeps dropping

Switch to the 5GHz band or use a wired Ethernet connection. Move your router closer if signal is weak.

FAQApp crashes or freezes

Go to Settings → Apps → [App Name] → Clear Cache. If the issue persists, uninstall and reinstall the app.

FAQVideo is not playing in 4K

Check that your TV supports 4K output, the HDMI cable is HDMI 2.0 or higher, and your streaming subscription includes 4K content.

FAQHow do I factory reset?

Go to Settings → Device Preferences → Reset → Factory Reset. This erases all data and restores factory defaults. Use only as a last resort.

Warranty & Support

Warranty Period

365 days from date of purchase

Coverage

Manufacturing defects and hardware failures under normal use

Not Covered

Physical damage, water damage, unauthorized modifications

Contact Support

support@colaboxtech.com
colaboxtech.com

Download the full PDF manual for offline reference
